Mobile Solar Tower lights
Explore T600W-7M
Charged by Solar and Wind Power
Luminaire Efficiency : 195LM/W
Illuminated Area ：900 – 1200㎡
Charging Time: 8 Hours
Working Time：More than 50 Hours
Battery Charging Type ：Solar + Wind Turbine
Features
High performance
Emergency lighting
360° Rotation
Solar energy
Remote control
Maximum runtime
Technical Parameters
| T600W-7M | Control Options | LCD panel (Remote Control + PC for your options) |
| PV Controller | MPPT 40A, 95% efficiency | |
| System Voltage | DC24V | |
| Working Temperature | -20℃ – 50℃ | |
| Charging Time | 8 hours | |
| Running Time | 50 hours | |
| IP rating | IP65 | |
| Lighting System | Type | 4*50W LED Flood Lights |
| Light Output | 39000lm | |
| Illuminated area @ 7m | 900 -1200 m2 | |
| Solar Panel and Wind Turbine | Solar Panel Wattage | 3*460W |
| Solar Panel Type | Mono crystalline Silicon, 21.7% efficiency | |
| Wind Turbine Rated Power | 300W | |
| Starting Wind Speed | 1m/s (2.24 mph) | |
| Safety Wind Speed | 50m/s (111.85 mph) | |
| Wind Turbine Type | Vertical axis wind turbines | |
| Battery and Inverter | Type | Lithium Battery |
| Battery Pack | 200AH DC25.6V 5120W.h | |
| Inverter Output | 110V / 240V / 380V Sine Wave | |
| Output Connections | 1* 10A + AC sockets + 1* 5A , USB2.0 | |
| Inverter Power | 3KW | |
| Lifting System | Type | Electric / Manual for your options |
| Mast Height | 2.5 – 6M Retractable | |
| Wind Resistance Rating | Level 8 117KM/H | |
| Materiall | Hot-Dip Galvanized Steel | |
| Trailer | Axle | Single |
| Tire and Rim | 2*14 inch Pneumatic Tires | |
| Stabilizer | 4 Support legs, Manual | |
| Tower Hitch | Ball Type, with towering eye ∅50mm | |
| Drawbar | USA / EU / AU standard | |
| Trailer Speed | 80 km/h | |
| Shipment | Transport Dimension | 2050*1883*2564mm |
| Deployed Dimension | 3070*3627*7000mm | |
| Total Weight | 1200kgs | |
| Loading Plan : | 40HQ: 6 pcs |
Application Scenario
Customization
01. Consultation
Discuss and finalize product specifications & requirements with the customer.
02. Design
Based on customer’s requirements, we will develop and finalize the the design with the approval by customer.
03. Quotation
Quote the prices and the estimated lead time for customer approval.
04. Sample Preparation & Approval
Sample fabrication and customer approval
05. Mass Production
According to customer approved product requirements and shipment date, we can start the quality-controlled mass production
06. Shipment
On-time shipment
